Code: 6001452
Loading...
| Wide-span version | no | Wire diameter | 4,8 mm |
|---|---|---|---|
| Screwless connector | yes | Profile shape | U-shaped |
| Integrated partition | Without | Support spacing 1.0 m | 0,9 kN/m |
| Fire protection | Use of fire protection ceilings | Type of connector, cable support system | Click fastening |
| Support spacing 1.5 m | 0,6 kN/m | Load test type according to IEC 61537 | Type II |
| Connector version | Integrated connector | Dimension H | 58 mm |
| Width | 19,69 in | Colour | zinc |
| Usable cross-section | 220 cm² | Support spacing 2.5 m | 0,25 kN/m |
| Support spacing 2.0 m | 0,3 kN/m | Rustproof steel, pickled | no |
| Maintain electrical functions | no | Height | 55 mm |
| Dimension B | 500 mm | CO₂ Footprint (GWP) Cradle-to-Gate | 5,124 kg CO₂e / 1 Meter |
| Surface | Electrogalvanized | Material | Steel |
| Length | 3000 mm | Dimension | 55x500x3000 |
