Code: 6000063
Loading...
| Usable cross-section | 5250 mm² | Wire diameter | 3,9 mm |
|---|---|---|---|
| Screwless connector | yes | Profile shape | U-shaped |
| Integrated partition | Without | Support spacing 1.0 m | 0,25 kN/m |
| Type of connector, cable support system | Click fastening | Support spacing 1.5 m | 0,11 kN/m |
| Load test type according to IEC 61537 | Type II | Connector version | Integrated connector |
| Width | 150 mm | Wide-span version | no |
| Colour | zinc | Support spacing 2.0 m | 0,1 kN/m |
| Rustproof steel, pickled | no | Maintain electrical functions | no |
| Height | 35 mm | Dimension B | 150 mm |
| CO₂ Footprint (GWP) Cradle-to-Gate | 1,2043 kg CO₂e / 1 Meter | Surface | Electrogalvanized |
| Material | Steel | Length | 3000 mm |
| Dimension | 35x150x3000 |
