Code: 6207314
Loading...
| Rustproof steel, pickled | no | Support spacing 6.0 m | 0,25 kN/m |
|---|---|---|---|
| Width | 750 mm | Wide-span version | no |
| Version of the rungs | Profile unperforated | Usable cross-section | 67500 mm² |
| Support spacing 5.0 m | 0,8 kN/m | Support spacing 4.0 m | 1 kN/m |
| Support spacing 3.0 m | 1,9 kN/m | Support spacing 2.0 m | 3,5 kN/m |
| Side rail version | Flat profile | Side perforation | yes |
| Colour | zinc | Rung distance | 300 mm |
| Rail thickness | 2 mm | Maintain electrical functions | no |
| Height | 110 mm | Fastening of rung | Welded |
| Dimension B | 750 mm | CO₂ Footprint (GWP) Cradle-to-Gate | 15,0186 kg CO₂e / 1 Meter |
| Surface | Hot-dip galvanised | Material | Steel |
| Length | 3000 mm | Dimension | 110x750x3000 |
