Code: 6216429
Loading...
| Rustproof steel, pickled | no | Width | 400 mm |
|---|---|---|---|
| Wide-span version | no | Version of the rungs | Profile perforated |
| Usable cross-section | 378 cm² | Support spacing 5.0 m | 0,5 kN/m |
| Support spacing 4.5 m | 0,5 kN/m | Support spacing 4.0 m | 0,65 kN/m |
| Support spacing 3.5 m | 0,9 kN/m | Support spacing 3.0 m | 1,4 kN/m |
| Support spacing 2.5 m | 2 kN/m | Support spacing 2.0 m | 3,1 kN/m |
| Side rail version | Flat profile | Side perforation | yes |
| Colour | zinc | Rung slot dimension | 16,50 |
| Rung distance | 300 mm | Rail thickness | 1,5 mm |
| Maintain electrical functions | no | Height | 110 mm |
| Fastening of rung | Blind riveted | Dimension B | 400 mm |
| CO₂ Footprint (GWP) Cradle-to-Gate | 10,2097 kg CO₂e / 1 Meter | Surface | Hot-dip galvanised |
| Material | Steel | Length | 3000 mm |
| Dimension | 110x400x3000 |
