Code: 2056372
Loading...
| Connectable conductor cross-section, multi-wire, max. | 6 mm² | Version of electrical connection 2 | Screw connection |
|---|---|---|---|
| Version of electrical connection 1 | Screw connection | Transparent | no |
| Suitable for solid conductors | yes | Suitable for multi-wire conductors | yes |
| Suitable for flexible conductors | yes | Pole number | 12 |
| Number of screwless terminals per pole | 2 | Nominal current | 57 A |
| No. of terminals | 12 | Drill hole spacing, centre | 11,5 mm |
| Connection position | Side | Connectable conductor cross-section, single-wire, min. | 2,5 mm² |
| Connectable conductor cross-section, single-wire, max. | 10 mm² | Connectable conductor cross-section, multi-wire, min. | 2,5 mm² |
| Colour | White | Connectable conductor cross-section, fine-wire without wire-end ferrule, min. | 2,5 mm² |
| Connectable conductor cross-section, fine-wire without wire-end ferrule, max. | 6 mm² | Closing plate required | no |
| Ambient temperature | 80 °C | Nominal voltage | 450 V |
| Nominal cross-section, min. | 10 mm² | Explosion-tested version | no |
| Cross-section | Max. attachment each side: 10 mm² single-wire or 6 mm² multi-wire/flexible mm² | Permitted temperature range, min. | -5 °C |
| Permitted temperature range, max. | 80 °C | Width | 23 mm |
| Height | 17 mm | Material | Polypropylene |
| Length | 134 mm | Dimension | 10,0mm² |
