Code: 2007914
Loading...
| Protection rating | IP67 | For Ex zone | Without |
|---|---|---|---|
| For Ex zone dust | Without | For Ex zone gas | Without |
| Halogen-free | yes | Measured insulation voltage Vi | 500 V |
| Mounting type | Wall/ceiling mounting | No. of entries | 7 |
| Nominal cross-section, min. | 6 mm² | Nominal voltage | 500 V |
| Flame-resistant | acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C | Protection rating IK code | IK07. |
| Sealable | yes | Shape | Square |
| Type of entry | Gland | Type of housing penetration | Pre-marking |
| Type of insertion | Plug-in seal | Weatherproof | no |
| with lid | yes | With screening | no |
| Clear internal dimensions | 100x100x48 mm | Dimension | 114x114x57 |
| Length | 114 mm | Material | Polypropylene |
| CO₂ Footprint (GWP) Cradle-to-Gate | 0,7238 kg CO₂e / 1 Piece | Height | 57 mm |
| Maintain electrical functions | Without | Width | 114 mm |
| Permitted temperature range, max. | 60 °C | Permitted temperature range, min. | -5 °C |
| Colour | Light grey; RAL 7035 | Cover | Not transparent |
| Cover fastening | Screwed | Entries | 7 x Ø20 |
| Entry from rear | yes | Equipment | Terminal |
| Expandable | yes | Explosion-tested version | no |
| Fibre-glass reinforced | no |
