Code: 2007029
Loading...
| Sealable | no | For Ex zone gas | Without |
|---|---|---|---|
| Halogen-free | yes | Measured insulation voltage Vi | 500 V |
| Mounting type | Wall/ceiling mounting | No. of entries | 4 |
| Nominal cross-section, min. | 2,5 mm² | Nominal voltage | 500 V |
| Protection rating | IP65 | Protection rating IK code | IK07. |
| For Ex zone dust | Without | Shape | Round |
| Type of entry | Cable | Type of housing penetration | Cuttable stepped membrane |
| Type of insertion | Plug-in seal | Weatherproof | no |
| with lid | yes | With screening | no |
| Diameter | 80 mm | Cover | Not transparent |
| Dimension | Ø80x51 | Material | Polypropylene |
| CO₂ Footprint (GWP) Cradle-to-Gate | 0,1873 kg CO₂e / 1 Piece | Height | 51 mm |
| Maintain electrical functions | Without | Permitted temperature range, max. | 60 °C |
| Permitted temperature range, min. | -5 °C | Clear internal dimensions | Ø63x45 mm |
| Colour | Light grey; RAL 7035 | Cover fastening | Locking |
| Entries | 4 x M25 | Entry from rear | yes |
| Expandable | yes | Explosion-tested version | no |
| Fibre-glass reinforced | no | Flame-resistant | acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C |
| For Ex zone | Without |
